·Smart power management with motion-triggered and remote activation ensures 24/7 vehicle monitoring, even when parked or unattended
·Supporting anti-theft protection, remote fleet diagnostics, standby surveillance, and real-time incident response in high-risk or off-hours operations
·Built-in 3-axis G-sensor detects sudden impact, harsh braking, or collision from any direction, automatically locking critical footage to prevent data loss
·Enabling accident evidence protection, insurance claim validation, driver behavior analysis, and real-time event recording in high-risk driving environments
| Operation System | Linux |
|---|---|
| CPU | ARM Cortex-A7 MP2 @950MHz |
| RAM | DDR 1GB |
| Memory Card | TF Card, 8GB–512GB |
| G-sensor | 3-Axis Acceleration Sensor |
| Speaker | 1 Channel, Built-in Amplifier & Speaker |
| Mic | 1 Channel, Built-in MIC |
| SIM Card | 1 Micro SIM Card Port |
| LED Indicators | Red: Power On Green Flash: Network Connecting Green: Network Connected |
| USB | Supports USB External Wi-Fi (No USB Flash Drive Access) |
| I/O Ports | 1 Digital Output, 1 Digital Input (SOS Button) |
| Cellular | 4G LTE Cat.1 |
|---|---|
| FDD LTE Bands | B1 / B3 / B5 / B8 |
| TDD LTE Bands | B34 / B38 / B39 / B40 / B41 |
| Wi-Fi | 2.4GHz, 802.11 b/g/n |
| Wi-Fi Usage | AP Mode |
| Protocol | JT/T808-2011, JT/T808-2019 JT/T1076-2016, JT/T1078-2016 |
| Front Camera | 1080P @ 25FPS |
|---|---|
| Cabin Camera | 1080P @ 25FPS |
| Infrared | Supported |
| Video Standards | PAL, NTSC |
| Compression Format | H.264 / H.265 |
| Resolution Options | 1080P, 720P, D1 |
| Total Encoding Resources | 1080P @ 60FPS |
| Video Quality Levels | Level 1 (Best) to Level 8 (Lowest) |
| Power Input | 9V–36V |
|---|---|
| Output Voltage | +5V @ 1A |
| Power Consumption | 325mA/H (average) |
| Power Protection | Overload, Undervoltage, Short-circuit, Reverse Connection |
| Low Power Mode | Sleep Online + Vibration Wake-up |
| Operating Temperature | -30℃ ~ +70℃ |
| Operating Humidity | 20% ~ 80% |
| GNSS | External Gmouse, TTL Level Interface |
| Positioning Frequency | Default: 20s, Min: 1s, Max: 600s |
| Supported Satellites | GPS + BDS |
